A-3EE12 Go Switch Low Profile Cordset - Single End - 3 Pin Female 12ft

How this assembly carries the signal between interfaces

1. Define each end

   Match the connector, contact arrangement and termination at each end to the equipment drawing. The free-lead end must be terminated inside the specified equipment interface.

2. Route the cable

   Choose length and construction for the installation. Allow the specified bend radius, strain relief and movement without loading the connector or termination.

3. Connect and verify

   Confirm pin-to-pin allocation, shielding and electrical checks for the finished assembly. Use the approved mating procedure; submersion capability alone does not permit underwater mating.

For this product: Review this assembly’s actual connector interfaces, conductor allocation, cable construction, installation route and complete assembly rating.
